Permeance
Description
Model of an ideal linear permeance \mathcal{P}. It represents a linear relationship between the magnetic flux \Phi and the magneto-motive force \mathcal{F}.
\mathcal{P} = \frac{\Phi}{\mathcal{F}}
Library
Magnetic > Branches
Parameters
| Property | Display Name | Parameter Type | Description |
|---|---|---|---|
| Value | Value [H] | DoubleParameter | Permeance value, in H |
| MMFinit | Initial MMF [A-Turn] | DoubleParameter | Initial Permeance MMF, in A-Turn |
Pins
| Property | Pin Name | Type | Description |
|---|---|---|---|
| P | P | Magnetic | Positive Pin (●) |
| N | N | Magnetic | Negative Pin |
Default Size
| Width | Height |
|---|---|
| 6 | 2 |
