Relational Operator
Description
Compares two control signals using a relational operator. The output is 1 when the relation is true and 0 otherwise.
Library
Control > Logic
Parameters
| Property | Display Name | Parameter Type | Description |
|---|---|---|---|
| Operator | Operator | RelationalParameterType | Relational operator applied between Input 1 and Input 2. |
| SamplingTime | Sampling Time [s] | DoubleParameter | Sampling Time |
Pins
| Property | Pin Name | Type | Description |
|---|---|---|---|
| In1 | In1 | ControlIn | Input 1 |
| In2 | In2 | ControlIn | Input 2 |
| Out | Out | ControlOut | Output |
Default Size
| Width | Height |
|---|---|
| 4 | 4 |
